Part Number: Rear Tension strut bolts and related hardware



Post new topic   Reply to topic    2GN.ORG Forum Index -> Part Numbers -> PN Chassis
View previous topic :: View next topic
Author Message
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #1   PostPosted: Wed Mar 25, 2009 5:20 pm    Post subject: Part Number: Rear Tension strut bolts and related hardware Reply with quote

Need the PN for the bolt and nut that connect the rear tension struts to the body of the car, I'll get pictures if need be
Thanks thumbup
_________________
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #2   PostPosted: Wed Mar 25, 2009 5:41 pm    Post subject: Reply with quote

Item 23 ) 6502502 NUT, Hex Flange Lock, M14x2


The "bolt" would be the tension strut if I understand you correctly.


STRUT, Stabilizer
5272250 Right
5272251 Left
_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #3   PostPosted: Wed Mar 25, 2009 5:48 pm    Post subject: Reply with quote

nope, I need the other end of the tension strut, where it attaches to the frame of the car. I'll run outside and snap some pics, it'll make more sense then.
_________________
Back to top
View user's profile Send private message
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #4   PostPosted: Wed Mar 25, 2009 6:06 pm    Post subject: Reply with quote

alright pictures should clear it up.
this is what I need. plus the nut that attaches to the bottom, the nut is not pictured.

here it is mocked up for reference with the bushing that holds the tension arm on

_________________
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #5   PostPosted: Wed Mar 25, 2009 6:19 pm    Post subject: Reply with quote

Nevermind, I was looking at the drawing backwards! Tard Bang

Item 29) 6505213AA SCREW AND WASHER Tension Strut

The drawing doesn't show the nut seperate. It may come with the part. If not I'm sure it could be had at any hardware store.


_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #6   PostPosted: Wed Mar 25, 2009 6:20 pm    Post subject: Reply with quote

Those diagrams always make my head hurt just looking at them.

thats what I needed thanks.
_________________
Back to top
View user's profile Send private message
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #7   PostPosted: Thu Mar 26, 2009 7:53 pm    Post subject: Reply with quote

Could I by chance get the thread and pitch size for these as well?
_________________
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #8   PostPosted: Fri Mar 27, 2009 3:46 am    Post subject: Reply with quote

That IDK. You may have to take the one you have to a hardware, and match it up with a nut to see what it is.

It's what I usually end up doing.

Unless someone else happens to have that info cluttering up their brain. Very Happy
_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #9   PostPosted: Fri Mar 27, 2009 8:16 am    Post subject: Reply with quote

ya that's kind of what i figured, thought is was worth a shot checking here first.

Edit...

Found it 12mm and pitch is 1.75 just in case anyone else needs to know.
_________________
Back to top
View user's profile Send private message
Midnight_Rider
2014 Platinum Contributor


Age: 58
Joined: 01 Aug 2006
Posts: 7951




Post: #10   PostPosted: Thu Jul 17, 2014 7:26 am    Post subject: Reply with quote

Did a Google search for this part number and got directed right to good ol' 2GN. Very Happy This may end up being the first hardware store bolt used on my car. bandhead
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #11   PostPosted: Thu Jul 17, 2014 8:57 am    Post subject: Reply with quote

I am not sure you will find something like that at a hardware store. Notice the upper and lower differences in size?

Sadly, yet another
Quote:
DISCONTINUED PART No Longer Available For Purchase




cussing
_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
Midnight_Rider
2014 Platinum Contributor


Age: 58
Joined: 01 Aug 2006
Posts: 7951




Post: #12   PostPosted: Thu Jul 17, 2014 9:24 am    Post subject: Reply with quote

Great- what the cussing do I do then? I've spent most of the morning on the phone, calling websites that don't show their correct inventory. bandhead
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #13   PostPosted: Thu Jul 17, 2014 9:27 am    Post subject: Reply with quote

What connects to the lower half of that?

If you have nothing, then a regular style bolt should work.

I wouldn't go less than an 8.8 to 10.9 grade.
_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #14   PostPosted: Thu Jul 17, 2014 10:12 am    Post subject: Reply with quote

The E brake attaches to the bottom half


Midnight_Rider wrote:
Great- what the cussing do I do then? I've spent most of the morning on the phone, calling websites that don't show their correct inventory. bandhead

Did yours snap off or are you just putting fresh ones on as preventative maintenance?

Id have to do some digging, but i think I have at least one maybe two of these lying around some where.
_________________
Back to top
View user's profile Send private message
Midnight_Rider
2014 Platinum Contributor


Age: 58
Joined: 01 Aug 2006
Posts: 7951




Post: #15   PostPosted: Thu Jul 17, 2014 1:26 pm    Post subject: Reply with quote

Boyscoutgonebad wrote:
Did yours snap off or are you just putting fresh ones on as preventative maintenance?
Preventative maintenance- I have the P4510870 Adjustable Rear Control Arm(s) and P4510826 Rear Tension Strut Kit and bought all new hardware for the day when I finally get them installed. The only part my dealership can't get new is the 6505312AA Tension Strut Screw and Washer and I need four (4) of them.
Back to top
View user's profile Send private message
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #16   PostPosted: Thu Jul 17, 2014 2:59 pm    Post subject: Reply with quote

That's what did four years ago just bought all new hardware, by now the new ones put on are probably covered in rust again. I remember at the time i ordered them thinking i should order a handful just to have around when the stopped making them
_________________
Back to top
View user's profile Send private message
Midnight_Rider
2014 Platinum Contributor


Age: 58
Joined: 01 Aug 2006
Posts: 7951




Post: #17   PostPosted: Thu Jul 17, 2014 6:01 pm    Post subject: Reply with quote

Sure wish that you had- I would offer you $$$ for them.
Back to top
View user's profile Send private message
Boyscoutgonebad
2GN Registrant


Age: 29
Joined: 03 Jun 2008
Posts: 365
Location: Findlay Ohio

2001 Dodge Neon R/T

Post: #18   PostPosted: Sun Jul 20, 2014 10:54 am    Post subject: Reply with quote

Let me know if you find anywhere to get them from. My car is about due for another suspension overhaul
_________________
Back to top
View user's profile Send private message
Midnight_Rider
2014 Platinum Contributor


Age: 58
Joined: 01 Aug 2006
Posts: 7951




Post: #19   PostPosted: Wed Jul 23, 2014 8:43 pm    Post subject: Reply with quote

Just bought four "recycled" ones on eBay. You might have to do something similar.

With this purchase, my SRT is now officially a used car. sad2
Back to top
View user's profile Send private message
jqt51
Fresh Fish


Age: 68
Joined: 11 Sep 2014
Posts: 1




Post: #20   PostPosted: Thu Sep 11, 2014 11:57 am    Post subject: Reply with quote

Part # 06505213AA Screw and washer. Tension Strut.

Part is said available at 'moparpartsoverstock.com' @$4.18 each + shipping. (US domestic)
Minimum order for international address is $100. As a canadian I can't just order four (4) screws. So if someone
like Boyscoutgonebad is on a project of overhauling his
rear suspension he or she might order 2 sets of screws and send back one set the other side of the border. Would
appreciate any help on getting one set of four 06505213AA
Back to top
View user's profile Send private message
Midnight_Rider
2014 Platinum Contributor


Age: 58
Joined: 01 Aug 2006
Posts: 7951




Post: #21   PostPosted: Thu Sep 11, 2014 7:21 pm    Post subject: Reply with quote

Good luck with that website- I called them when I was going down the list of places that Google came up with when I searched for that part number and was told that they didn't have any (just like everyone else).
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #22   PostPosted: Tue May 16, 2017 11:33 am    Post subject: Reply with quote

Mopar Parts Giant also says they have them. I am waiting for confirmation from their warehouse.

Not holding my breath.

Probably have to use Dawm's suggestion of drilling the e-brake bracket to 12mm and using 12mm x 1.75 screws.
_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
Midnight_Rider
2014 Platinum Contributor


Age: 58
Joined: 01 Aug 2006
Posts: 7951




Post: #23   PostPosted: Thu May 25, 2017 11:10 pm    Post subject: Reply with quote

^^ Email sent.
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #24   PostPosted: Tue Sep 12, 2017 1:33 pm    Post subject: Reply with quote

4656357AA

Is the two rubber bushings that go in the knuckle end.

No longer available from FCA.

The 4656361AA Bushing Retainer (washer) is also not available. Like the bushing, they are shown on some sites, but a phone call confirms they are not in stock.


Moog K4728
_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
BlackRoseRacing
1st ever DD SC 2GN!
2009 Platinum Contributor


Age: 38
Joined: 25 Dec 2004
Posts: 12696


2002 Dodge Neon R/T

Post: #25   PostPosted: Thu Sep 14, 2017 10:10 pm    Post subject: Reply with quote

holy post resurrection laughing3
Back to top
View user's profile Send private message
occasional demons
Mr One World
Moderator


Age: 51
Joined: 03 May 2007
Posts: 19779
Location: Ashland, Ohio

2001 Dodge Neon ES

Post: #26   PostPosted: Fri Sep 15, 2017 5:44 am    Post subject: Reply with quote

Figured as these become older/worn out, it may be nice to have an easy solution...
_________________
Bill


2001 neon ES MTX with '02 R/T PCM
1999 neon 2.4 EDZ MTX
Help support 2GN!
Back to top
View user's profile Send private message AIM Address
Display posts from previous:
Post new topic   Reply to topic    2GN.ORG Forum Index -> Part Numbers -> PN Chassis All times are UTC - 8 Hours
Page 1 of 1


Jump to:
You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot vote in polls in this forum


Powered by p h p B B © 2001, 2005 p h p B B Group
2GN.org Decals
MidwestNeons.com
