How To: Replace ALL Speakers - PICS FIXED!!!

Post by Hudson_Neon » Sun Sep 02, 2007 12:47 pm

ok, so there was a discussion in the audio section and i told the guy that i'd do a how-to, so here it is...

DASH SPEAKERS:

start by removing the screws on the sides when you open the doors

then the screws up in the vent on top of the dash

then remove the A-Pillar covers, i found that just giving them a tug works

then lift the dash up and out

then put your new speakers in

reverse for putting it back together

DOOR SPEAKERS:

start by removing these three screws

then go around the edges and pry the door panel off, i recommend plastic pry tools, i got the "expensive" set http://www.genuinehotrod.com/SearchResu ... Search=pry


then disconnect the linkage and any plug-ins

next remove the plastic that angles the speaker and put your new speaker in

do the same for both doors in front. reverse for putting it together. remember to plug everything back in

REAR DECK SPEAKERS:

start by grabbing the bottom half and lift up, comes out rather easy

then remove the four T-55 Torx bolts, you might need a cheater bar

next give the seat-back a little lift and it's out

then just pull the carpeting down and replace your speakers

reverse everything when putting it back together. remember when you put the seat-back back in to place that it slides in on the top and put the outside belts on the front side of the seat so as not to bolt them down... that sucks

i hope that that's everything
Last edited by Hudson_Neon on Thu Mar 29, 2012 11:31 am, edited 2 times in total.

ZeroChad
2009 Gold Contributor
Posts: 3165
Joined: Sat Sep 01, 2007 11:08 pm
Location: Austin, Tx
Contact:

Post by ZeroChad » Sun Sep 02, 2007 1:12 pm

After undoing those huge torque for the back seat a few times, I found out that you can actually just take off the carpet on the rear deck if you use some ingenuity.

Removing the rear seat is probably the proper way to do it though, it also gives you more access into the trunk to install your speakers. But if you're looking to save some time...
Old Neon Log | Feedback

2000 - Corvette Coupe
2002 - Neon SE Fully Built (scrapped)

o2bfishn
2GN Member
Posts: 157
Joined: Mon Jan 08, 2007 1:08 am
Location: Kannapolis, NC

Post by o2bfishn » Sun Sep 02, 2007 1:26 pm

thanks for the how to :thumbup:
I may not have been born in the South, but I got here as fast as I could!


User avatar
60trim
2GN Member
Posts: 800
Joined: Wed Oct 20, 2004 6:26 pm
Location: Aurora, Colorado
Contact:

Post by 60trim » Tue Sep 04, 2007 3:26 pm

Good post.
2003 Silver SXT - Totalled
2005 Silver Subaru Legacy 2.5GT Turbo -Daily
1990 White SR powered 240sx - My sliding slut.

I miss my neon at times. She treated me well and taught me a lot about cars in general. I will always have a special place in my heart for these cars. Heres to the 2gn community.

Hudson_Neon
2GN Member
Posts: 3371
Joined: Wed Mar 14, 2007 4:50 pm

Post by Hudson_Neon » Tue Dec 18, 2007 8:52 am

just bumpin this cause i've been poking my head in the audio section and there ALWAYS seems to be somebody wondering how to do this...

i may be a little biased, but i would think that making it a sticky at in the audio section might help

sullygully
2GN Member
Posts: 1267
Joined: Mon Aug 08, 2005 8:23 pm
Location: Banff, Alberta

Post by sullygully » Tue Dec 18, 2007 2:06 pm

+1 for sticky

titansxt
2GN Member
Posts: 2848
Joined: Wed May 12, 2004 11:24 am
Location: IL

Post by titansxt » Tue Dec 18, 2007 2:27 pm

When you put the water damn back up (the plastic) make sure its still all sticky. If not, make it sticky and put it back up. Also, when putting the rear cushion back in sometimes the latches (the metal part) don't want to go in place. All you have to to is push the cushion towrds the rear of the car, and put your knee on the seat until in pops in place. Oh, and nice HT. :thumbup:
2003 SXT
2005 SRT-4
2gn.org member #26 :tard:
Lemon Neon member #1.
Any or all of the above statement(s) may be entirely fictional and a fabrication. :lol:
ram50rocket wrote: I must had been mistaken in thinking that NEONS.ORG was just for neons.

Hudson_Neon
2GN Member
Posts: 3371
Joined: Wed Mar 14, 2007 4:50 pm

Post by Hudson_Neon » Tue Dec 18, 2007 7:56 pm

you shouldn't have to pull off the water dam... unless you're runnin all new wires.

trinity_rush2001
2GN Member
Posts: 423
Joined: Mon Jul 30, 2007 9:02 pm
Location: killeen TX

Post by trinity_rush2001 » Thu Jul 03, 2008 3:51 pm

is there any other way to break loose those Tork bolts ive tryed everything i have and not luck its like mine are welded

User avatar
jetas
2GN Member
Posts: 1908
Joined: Sat Dec 01, 2007 3:57 pm
Location: Killa Cali

Post by jetas » Thu Jul 03, 2008 4:47 pm

A breaker bar if you have access to one.
-J.J. | Official I sold my Neon Member #008
86.5 Nissan Hardbody LB- will be for sale soon...

1989 Yota PU- "Tammy" -Rest In Pieces...

2000 Plym Neon- "Stacy" -Sold 3/25/09 =(
Ntyvirus1 wrote:im debadged so i just drive a gray thing.

trinity_rush2001
2GN Member
Posts: 423
Joined: Mon Jul 30, 2007 9:02 pm
Location: killeen TX

Post by trinity_rush2001 » Thu Jul 03, 2008 5:12 pm

hmmm i might have to go to autozone

User avatar
jetas
2GN Member
Posts: 1908
Joined: Sat Dec 01, 2007 3:57 pm
Location: Killa Cali

Post by jetas » Thu Jul 03, 2008 5:15 pm

Or just get a pipe thats big enough for the ratchet handle to fit in. Anything to give u more leverage
-J.J. | Official I sold my Neon Member #008
86.5 Nissan Hardbody LB- will be for sale soon...

1989 Yota PU- "Tammy" -Rest In Pieces...

2000 Plym Neon- "Stacy" -Sold 3/25/09 =(
Ntyvirus1 wrote:im debadged so i just drive a gray thing.

Hudson_Neon
2GN Member
Posts: 3371
Joined: Wed Mar 14, 2007 4:50 pm

Post by Hudson_Neon » Fri Jul 04, 2008 9:57 am

yeah... a "cheater bar". i like to use a pipe or a large box-end wrench

User avatar
Swordfish2Cowboy
2009 Silver Contributor
Posts: 2693
Joined: Sat Aug 25, 2007 7:06 am
Location: Sandusky, Ohio

Post by Swordfish2Cowboy » Fri Jul 04, 2008 1:07 pm

Spray the bolts with penetrating fluid. I had my seats out for about a month and didn't tighten the bolts all the way down. Now they don't want to go in, thinking there's a hole in the bottom and water is getting in.
:mopar: :runaway:

Car6on14
2GN Member
Posts: 43
Joined: Mon Nov 17, 2008 10:33 am
Location: Scranton PA
Contact:

Post by Car6on14 » Tue Dec 02, 2008 4:46 pm

what size are the speakers in the dash? Seems the back is 6 X 9 and doors r 6.5 from what ive read, but havent found dash...
05 Sxt 5spd w/ SRT body styling
http://www.cardomain.com/id/Car6on14

occasional demons
Junior Admin
Posts: 19162
Joined: Thu May 03, 2007 12:14 pm
Location: Ashland Ohio

Post by occasional demons » Tue Dec 02, 2008 5:38 pm

From Crutchfield.
In-dash stereo
7-3/16" depth; Size code E
Front speakers
Dash: 3-1/2"
Front Door: 6-3/4"
Rear speakers
Rear Deck: 6x9"
I just bought tweeters and fabbed a mount for them. Used the factory speakers for the template, and tin snipped away.
Bill
dblsg wrote:ya'll a bunch of post whores
epic

2001 Neon ES MTX with '02 R/T PCM
Help support 2GN!

matguy
2GN Member
Posts: 30
Joined: Tue Jul 15, 2008 6:02 pm
Location: Seattle-ish

Post by matguy » Fri Dec 19, 2008 12:57 pm

What's funny though is that even though Crutchfield lists the fronts as 3.5", they seem to think that none of their 3.5" speakers fit a Neon.

Well, maybe not funny to people wondering if there is any mounting issues with "standard" aftermarket 3.5" speakers.

Hudson_Neon
2GN Member
Posts: 3371
Joined: Wed Mar 14, 2007 4:50 pm

Post by Hudson_Neon » Fri Dec 26, 2008 7:17 pm

well i don't know what they're thinking. cause these are the speakers that i have in my dash

JRT-4
2GN Member
Posts: 65
Joined: Mon Aug 20, 2007 11:30 pm
Location: Tappahannock,Va

Post by JRT-4 » Tue Jul 13, 2010 2:30 pm

Do aftermarket 6.5s fit in the plastic piece in the door? If so I need to find a drivers door plastic piece.
O2 Neon Atx
preswap W/cracked header 17.77@79.11
103whp 109wtq
After swap 13.736@95.38
[View Timeslip]
300whp 373wtq
SRT-4 Swap DONE!!

Jr1
2GN Member
Posts: 58
Joined: Sun Sep 25, 2011 6:47 pm
Location: slippery rock,pa

Post by Jr1 » Mon Nov 28, 2011 11:03 am

none of the pix are working in the 1st post.. :banghead:

Hudson_Neon
2GN Member
Posts: 3371
Joined: Wed Mar 14, 2007 4:50 pm

Post by Hudson_Neon » Mon Nov 28, 2011 11:07 am

yeah, they were on myspace from AGES ago... this thread should probably be locked for being useless now without pics

occasional demons
Junior Admin
Posts: 19162
Joined: Thu May 03, 2007 12:14 pm
Location: Ashland Ohio

Post by occasional demons » Mon Nov 28, 2011 12:21 pm

Looks like a bust.





:lol:



Unlocked per OP's request. :thumbup:
Bill
dblsg wrote:ya'll a bunch of post whores
epic

2001 Neon ES MTX with '02 R/T PCM
Help support 2GN!

User avatar
D-Railed_Neon
2011 Bronze Contributor
Posts: 723
Joined: Sun Oct 23, 2011 8:39 pm
Location: Bellevue, NE

Post by D-Railed_Neon » Tue Apr 17, 2012 11:25 pm

Maybe trying to bring this back from the dead may be too much to ask but, does anyone have specific advise for aftermarket dash 3.5"s? Part numbers, links, and/or pics, greatly appreciated. Thanks guys, hopefully someone out there hears this. lol
MY PROJECT LOG My Old 2002 ES AND My 2003 SXT

It is not that we cannot be friends, it's that you are a zombie, and I am almost out of ammo. -Someone

Hudson_Neon
2GN Member
Posts: 3371
Joined: Wed Mar 14, 2007 4:50 pm

Post by Hudson_Neon » Wed Apr 18, 2012 2:08 am

mine are rockford fosgate. they're a little older than this, but you get the idea.

http://www.rockfordfosgate.com/products ... mid=112881

i like the way that they sound. decent price too

User avatar
D-Railed_Neon
2011 Bronze Contributor
Posts: 723
Joined: Sun Oct 23, 2011 8:39 pm
Location: Bellevue, NE

Post by D-Railed_Neon » Wed Apr 18, 2012 2:13 am

Thank you sir!! now are any mods needed to run with a oem deck? (I have an RB4 that controls my dash speakers at the moment.) I just wonder if there is a difference in impedance from the stockers to aftermarket like these. it says 4 ohm so, should be direct fit no rewire or mods necessary, amiright? Thanks for your help and advise
MY PROJECT LOG My Old 2002 ES AND My 2003 SXT

It is not that we cannot be friends, it's that you are a zombie, and I am almost out of ammo. -Someone

Hudson_Neon
2GN Member
Posts: 3371
Joined: Wed Mar 14, 2007 4:50 pm

Post by Hudson_Neon » Wed Apr 18, 2012 11:36 am

well i can't speak on the terms of the RB4, but all i did was splice the speaker into the stock harness.

User avatar
D-Railed_Neon
2011 Bronze Contributor
Posts: 723
Joined: Sun Oct 23, 2011 8:39 pm
Location: Bellevue, NE

Post by D-Railed_Neon » Wed Apr 18, 2012 12:38 pm

Perfect. The only reason I mention my RB4 is bc it is currently running my stock dash speakers. So since these new aftermarket speakers are the same specs, I should be able to drop em in and go. I am a happy camper. Thank you sir! :thumbup:
MY PROJECT LOG My Old 2002 ES AND My 2003 SXT

It is not that we cannot be friends, it's that you are a zombie, and I am almost out of ammo. -Someone

NickKo
2009 Gold Contributor
Posts: 2248
Joined: Sun Jun 11, 2006 11:24 am
Location: IL./WI.border

Re: How To: Replace ALL Speakers - PICS FIXED!!!

Post by NickKo » Sat Apr 21, 2012 7:29 pm

Hudson_Neon wrote: the screws up in the vent on top of the dash
THANKS for posting pictures of those stoopid screws !! :lol:

Those are the first pics of those, that I have ever seen.
People have trouble 'finding' those, because they are somewhat invisible and folks don't know, that they are even there.
